Introduction to ISTA Packaging and Transportation Release Time:2021-11-26

ISTA (International Safe Transit Association), the International Safe Transit Association, is an international non-profit organization dedicated to improving the safety of transportation packaging and reducing product losses during transportation. ISTA has developed a series of packaging safety transportation test procedures, such as ISTA 1 series (not simulated transportation test at all), ISTA 2 series (partially simulated transportation test), ISTA 3 series (completely simulated transportation test), ISTA 6 series (member customized test procedures) and so on.




The main test series of ISTA are as follows:



ISTA 1A (≤68kg, single package, regardless of package type)

ISTA 3A series ISTA 3A (≤70 kg, packages shipped in parcels)

ISTA 3B series ISTA 3B (≤70kg, LTL freight package (truck transportation)

ISTA 3E series ISTA 3E (≤70 kg, collective packaging unit for the same product)

ISTA 6 series ISTA 6A (≤70kg, customized by FedEx)



Introduction to some test procedures



1. ISTA3 series test procedures


It is a comprehensive simulation performance test, which simulates the damage to the package caused by various movements, forces, transportation conditions, transportation environment and the sequence of occurrence in the laboratory. Used in a variety of transportation environments, such as: different vehicle types, different intermodal routes, and different handling processes. Including random vibration, drop tests at different heights, and/or environmental handling tests, such as damp heat or extreme cold/freezing points.


1.   ISTA 3A is for packages that have a mass of not more than 70kg (150 pounds) and are transported in parcels



Serial   number

Project

Remark

1

Temperature and humidity treatment


2

Free fall


3

Vibration (with/without load)


4

Free fall


5

Rotating edge drop

Flat/Long Strip Packaging

6

Tip over

Flat/Long Strip Packaging

7

Concentrated impact

Flat packaging

8

Bridging impact

Long strip packaging

9

Leak test

Liquid packaging



2、ISTA 3B LTL package.


A comprehensive simulation test for transportation using a car (truck) delivery and distribution system. The distribution system has different types of packages, usually from multiple shippers to multiple different destinations, and mixed transportation. This type of transportation is called LTL transportation.



Serial   number

Project

Remark

1

Temperature and humidity treatment


2

Tip over


3

Free fall


4

Load vibration


5

Concentrated impact

Suitable for non-rigid containers

6

Free fall


7

Tip over

Long strip/Flat packaging

8

Bridging impact

Long strip packaging

9

Concentrated impact

Flat packaging



3、ISTA 3E is a collective packaging unit for the same product


Serial   number

Project

1

Temperature and humidity treatment

2

Inclined impact

3

Rotating edge drop

4

Compressive

5

vibration

6

Rotating edge drop



ISTA 6 series test procedure


The ISTA 6 series test procedure is jointly developed by ISTA and ISTA member companies. Currently, there are ista6-Boxing (Amazon), ista6--S1.O.C. (T Mason), ISTA 6 FEDEX-A (FedEx).


1.       ISTA 6 FEDEX-A (customized by FedEx members)



Serial number

Product Category

Project

Remark

1

Transportation   of electronic appliances and medical products in the United States



fall


2

Concentrated impact

Flat packaging

3

Bridging impact

Long strip packaging

4

Compressive


5

vibration


1

Other   products shipped within the U.S.



fall


2

Concentrated impact

Flat packaging

3

Bridging impact

Long strip packaging

4

Compressive


5

Rotational vibration


1

International   Transport

fall


2

Concentrated impact

Flat packaging

3

Bridging impact

Long strip packaging

4

Compressive


5

vibration


6

fall




2、ISTA 6-Amazon.com-SIOC (customized by Amazon member)


The test standard is an agreement that Amazon and its suppliers’ products need to follow in Amazon’s operating environment. The packaging products used for "own packaging and transportation" are transported to the end user through the Amazon distribution system to simulate the test---that is, the products of the supplier, manufacturer or manufacturer are placed in their own packaging containers and transported to the Amazon distribution center and then passed through Parcel or LTL overseas. It is mainly aimed at individually packaged products that weigh less than 23kg and are transported in packages without pallets when they reach consumers. According to the packaging size, weight, delivery method and product category, the products are divided into 8 categories of Type A~Type H for testing. The details are as follows:



Serial number

Classification

Specific instructions

1

Type A

Individually   packaged products that weigh less than 23kg and are transported in packages   without pallets when delivered to consumers.

2

Type B

Individually   packaged products that the weight is 23kg~43kg and are   transported in packages without pallets when delivered to consumers.

3

Type C

Individually   packaged products that weigh greater than or equal to 43kg and are   transported in packages without pallets when delivered to consumers.

4

Type D

Individually   packaged products that weigh less than 43kg and are transported in packages   without pallets when delivered to consumers.

5

Type E

Individually   packaged products with a weight greater than or equal to 43kg, delivered to   consumers without a pallet, and transported with LTL shipment.

6

Type F

Individually   packaged products delivered to consumers without a pallet, and transported   with LTL shipment.

7

Type G

It is   suitable for TY/display, without pallet, weight less than 68kg and perimeter   less than or equal to 4.19m, individually packaged products with LTL   shipment.

8

Type H

It is   suitable for TY/display, without pallet, weight greater than or equal to 68kg   and perimeter greater than 4.19m, individually packaged products with LTL   shipment.



The main test items are as follows:



Serial number

Test items

Remark

1

Temperature   and humidity treatment


2

Free   fall


3

Vibration   (with/without load)


4

Free   fall


5

Rotating   edge drop

Flat/Long   Strip Packaging

6

Tip   over

Flat/Long   Strip Packaging

7

Concentrated   impact

Flat   packaging

8

Bridging   impact

Long   strip packaging

9

Leak   test

Liquid   packaging



3、ISTA6-Amazon.com-Over Boxing (customized by Amazon member)


The ISTA6-Amazon.com-Over Boxing test is mainly for a single retail packaged product to be placed in the main shipping container alone, with padding (air pillow or kraft paper) or multiple independent retail packaged products added. Products that pass the ISTA6-Amazon.com-Over Boxing test are to be delivered to terminal consumers from the Amazon website through a package delivery system, which may include air, rail, or truck models. For single packaged products weighing less than 23kg.


Serial number

Project

1

Temperature   and humidity treatment

2

Free   fall

3

vibration

4

fall
